92 000 Lift & Slide Series

Highly thermally insulated sliding and lift-and-slide system with perfect water tightness, outstanding sound reduction. Based on single, double and triple-track outer frames, Everest creates large opening widths with outstanding user comfort. Perfect for use as a high-quality system solution in commercial projects and luxury residential properties. The 92000 series ensures that the sliding leaf can be operated easily and securely.

Technical data
Exterior visible width 136 mm [5.35”]
Frame Depth 164 mm [6.5”]
Sash Depth 65 mm [2.6”]
Glass Thickness ≤ 45 mm [≤ 1.8”]
Thermal Insulation Polyamide 20 mm [0.8”]
Sash mechanism weight limit 300-400 kg [661.4-881.9 lbs]
Uf 1.67 W/m2K [0.294 BTU/h ft2°F]
